SUER1 TYPE
Stuff should be placed here.
ASW-05A4/SUER1
- BTU : 5000
- EER(BTU/h/w) : 10.0
- Rated Power Consumption : 500W
- Rated Running Current : 2.3A
- Power Supply Source : 220V/50 Hz
- Refrigerant : R410a
- Refrigerant Charged : 360 g
- Air Flow Volume : 410 m³/h
- Noise Level
Indoor: 38 dB(A)
Outdoor: 48 dB(A)
- Net Weight
Indoor: 7 Kg
Outdoor: 20 Kg
- Net Dimension (mm)(W x D x H)
Indoor: 802 x 190 x 265
Outdoor: 663 x 254 x 421
- Packing Dimension (mm)(W x D x H)
Indoor: 860 x 255 x 325
Outdoor: 770 x 338 x 478
ASW-09A4/SUER1
- BTU : 9000
- EER(BTU/h/w) : 9.6
- Rated Power Consumption : 940W
- Rated Running Current : 4.3A
- Power Supply Source : 220V/50 Hz
- Refrigerant : R410a
- Refrigerant Charged : 550 g
- Air Flow Volume : 440 m³/h
- Noise Level
Indoor: 38 dB(A)
Outdoor: 49 dB(A)
- Net Weight
Indoor: 7 Kg
Outdoor: 24 Kg
- Net Dimension (mm)(W x D x H)
Indoor: 802 x 190 x 265
Outdoor: 700 x 231 x 489
- Packing Dimension (mm)(W x D x H)
Indoor: 860 x 255 x 325
Outdoor: 835 x 335 x 545
ASW-12A4/SUER1
- BTU : 12000
- EER(BTU/h/w) : 9.6
- Rated Power Consumption : 1250W
- Rated Running Current : 5.8A
- Power Supply Source : 220V/50 Hz
- Refrigerant : R410a
- Refrigerant Charged : 900 g
- Air Flow Volume : 650 m³/h
- Noise Level
Indoor: 43 dB(A)
Outdoor: 53 dB(A)
- Net Weight
Indoor: 9.5 Kg
Outdoor: 28 Kg
- Net Dimension (mm)(W x D x H)
Indoor: 880 x 203 x 286
Outdoor: 760 x 260 x 540
- Packing Dimension (mm)(W x D x H)
Indoor: 935 x 270 x 350
Outdoor: 880 x 370 x 600
ASW-18A4/SUER1
- BTU : 18000
- EER(BTU/h/w) : 10.8
- Rated Power Consumption : 1880W
- Rated Running Current : 8.5A
- Power Supply Source : 220V/50 Hz
- Refrigerant : R410a
- Refrigerant Charged : 1430 g
- Air Flow Volume : 850 m³/h
- Noise Level
Indoor: 47 dB(A)
Outdoor: 57 dB(A)
- Net Weight
Indoor: 11 Kg
Outdoor: 42 Kg
- Net Dimension (mm)(W x D x H)
Indoor: 940 x 232 x 300
Outdoor: 800 x 300 x 590
- Packing Dimension (mm)(W x D x H)
Indoor: 993 x 285 x 360
Outdoor: 940 x 420 x 750
ASW-24A4/SUER1
- BTU : 24000
- EER(BTU/h/w) : 11.8
- Rated Power Consumption : 2037W
- Rated Running Current : 9.2A
- Power Supply Source : 220V/50 Hz
- Refrigerant : R410a
- Refrigerant Charged : 1650 g
- Air Flow Volume : 1100 m³/h
- Noise Level
Indoor: 49 dB(A)
Outdoor: 59 dB(A)
- Net Weight
Indoor: 17 Kg
Outdoor: 52 Kg
- Net Dimension (mm)(W x D x H)
Indoor: 1080 x 220 x 300
Outdoor: 800 x 300 x 690
- Packing Dimension (mm)(W x D x H)
Indoor: 1136 x 285 x 360
Outdoor: 940 x 420 x 750
